Industrial Inkjet Printer
Videojet® 1580+
A continuous inkjet printer designed to improve the performance of everyday operations.
The Videojet 1580 industrial inkjet (CIJ) printer enables uninterrupted operation without downtime, evaluates individual printer consumption patterns, and provides guidance to help ensure error-free operation over a long period of time, with reduced operating costs.
Videojet OPTIMiZE provides on-screen alerts with full diagnostics, analytics, and guidance for improving everyday printer performance.
The Videojet SIMPLICiTY™ interface reduces operator interventions on the printer, helping to eliminate potential user errors through an intuitive 10-inch touchscreen display.
Achieve consistent print quality with Dynamic Calibration™, which automatically adjusts to changes in temperature and viscosity. Built-in Wi-Fi and web server capability enable simple and secure wireless communication.
Prevent potential downtime with at least 8 additional hours of operation using the integrated make-up fluid tank, helping to protect production under normal operating conditions.
| Specification | Value / Feature |
|---|---|
| Ink | Fast-drying, dye-based ink |
| Maximum number of print lines per printhead | 5 |
| Maximum print speed (1) | 278 m/min (914 ft/min) |
| Protection rating | IP55 (Dust Kit IP65 #) |
| Umbilical cable length | 3 m (9.8 ft), optional 6 m (19.6 ft) |
| Stored message capacity | More than 250 complex messages |
| Smart Cartridge™ fluid delivery system | Yes |
| Plug and Play modular printhead | Yes |
| USB | Yes |
| Communication | Ethernet LAN and RS232 Serial (requires RS232 connector), built-in Wi-Fi, and optional mobile network connectivity |
| Linear and 2D barcodes | Yes |
| Positive Air / CleanFlow™ | Optional |
| Display / user interface | SIMPLICiTY™ based on a 10″ colour touchscreen |
Uptime Advantage
- Prevent potential downtime with at least 8 additional hours of operation using the integrated make-up fluid tank, helping to protect production under normal operating conditions.
- Easy and reliable replacement of service parts, without production downtime.
- Videojet Dynamic Calibration automatically maintains exceptional print quality, enabling uninterrupted operation in changing environmental conditions.
Simple Operation
- Reduce the possibility of coding errors with the programmed message creation function.
- Automate message content without operator intervention using defined user fields.
- Simplify message creation and setup to start product coding faster.
Code Assurance
- Eliminate potential user errors with the Videojet SIMPLICiTY™ interface, which significantly reduces operator interaction with the printer.
- Easy-to-use 10-inch touchscreen display.
- Customise the interface using built-in templates and access video guides for printer operation and maintenance.
Improved Productivity
- Built-in Wi-Fi and web server capability enable simple and secure wireless communication.
- Analyse your own operating system and take advantage of opportunities to improve printer performance through on-screen alerts.
- The web server enables access to printers via supported internet browsers on host comp
| Specification | Value / Feature |
|---|---|
| Ink | Fast-drying, dye-based ink |
| Maximum number of print lines per printhead | 5 |
| Maximum print speed (1) | 278 m/min (914 ft/min) |
| Protection rating | IP55 (Dust Kit IP65 #) |
| Umbilical cable length | 3 m (9.8 ft), optional 6 m (19.6 ft) |
| Stored message capacity | More than 250 complex messages |
| Smart Cartridge™ fluid delivery system | Yes |
| Plug and Play modular printhead | Yes |
| USB | Yes |
| Communication | Ethernet LAN and RS232 Serial (requires RS232 connector), built-in Wi-Fi, and optional mobile network connectivity |
| Linear and 2D barcodes | Yes |
| Positive Air / CleanFlow™ | Optional |
| Display / user interface | SIMPLICiTY™ based on a 10″ colour touchscreen |
Uptime Advantage
- Prevent potential downtime with at least 8 additional hours of operation using the integrated make-up fluid tank, helping to protect production under normal operating conditions.
- Easy and reliable replacement of service parts, without production downtime.
- Videojet Dynamic Calibration automatically maintains exceptional print quality, enabling uninterrupted operation in changing environmental conditions.
Simple Operation
- Reduce the possibility of coding errors with the programmed message creation function.
- Automate message content without operator intervention using defined user fields.
- Simplify message creation and setup to start product coding faster.
Code Assurance
- Eliminate potential user errors with the Videojet SIMPLICiTY™ interface, which significantly reduces operator interaction with the printer.
- Easy-to-use 10-inch touchscreen display.
- Customise the interface using built-in templates and access video guides for printer operation and maintenance.
Improved Productivity
- Built-in Wi-Fi and web server capability enable simple and secure wireless communication.
- Analyse your own operating system and take advantage of opportunities to improve printer performance through on-screen alerts.
- The web server enables access to printers via supported internet browsers on host comp
