Industrial Inkjet Printer

Videojet® 1620FG

PERFECT FOR APPLICATIONS IN THE FOOD INDUSTRY

Continuous Inkjet Printer for the Food Industry
The Videojet 1620FG industrial inkjet printer provides outstanding reliability for marking and coding applications in the food industry, ensuring smooth operation and high print quality.

Equipped with CleanFlow™ and Dynamic Calibration™ technologies, the 1620FG is designed to deliver extended uptime, significantly reducing the need for manual maintenance and increasing production efficiency.

The 1620FG printer for the food industry is specially adapted for demanding applications. It can store up to 250 complex messages, simplifying message retrieval and improving operational flexibility.

The 1620FG uses specially formulated inks for the food industry, fully compliant with industry standards and regulations.

Specification Value
Printhead 1
Inks Fast-drying
Maximum print speed (1) 293 m/min
Protection rating IP65
Maximum number of print lines 5
Hose length 3 m, optional 6 m
Number of stored messages 250
Smart Cartridge™ fluid delivery system Yes
Plug and Play modular printhead No
USB Yes
Communication RS232 / RS485 / Ethernet
Internal air pump / CleanFlow™ Optional
Extended I/O ports and control No
Display / user interface 320 × 240, 5.7-inch LCD

Flexibility

  • Simple integration with Videojet CLARiSOFT and CLARiSUITE software
    • Enables remote management of advanced marking and coding options
    • Prints from 1 to 5 lines of text
    • Separate operation settings from installation and maintenance settings

Consistency

  • CleanFlow™ printhead technology prevents ink build-up that can cause downtime in standard inkjet printers
    • Long intervals between routine servicing, with up to 14,000 hours of core module life
    • Dynamic Calibration™ technology automatically adjusts ink jetting parameters to ensure high print quality
    • Automatic printhead cleaning for fast start-up after longer periods of inactivity

Expertise

  • The absence of external air in the internal air pump reduces the potential risk of contaminants entering the ink drop stream
    • The Smart Cartridge™ printing system virtually eliminates ink spills

Functionality

  • Multiple password-protected access levels in the system control menus help prevent accidental input errors
    • Stored print information, with pre-set and calculated fields, minimises the need for user input
    • Simple operation via a bright WYSIWYG display and function keys
    • Stores up to 250 complex messages for easy reuse, with additional capacity available using a standard USB memory device.

Specification Value
Printhead 1
Inks Fast-drying
Maximum print speed (1) 293 m/min
Protection rating IP65
Maximum number of print lines 5
Hose length 3 m, optional 6 m
Number of stored messages 250
Smart Cartridge™ fluid delivery system Yes
Plug and Play modular printhead No
USB Yes
Communication RS232 / RS485 / Ethernet
Internal air pump / CleanFlow™ Optional
Extended I/O ports and control No
Display / user interface 320 × 240, 5.7-inch LCD

Flexibility

  • Simple integration with Videojet CLARiSOFT and CLARiSUITE software
    • Enables remote management of advanced marking and coding options
    • Prints from 1 to 5 lines of text
    • Separate operation settings from installation and maintenance settings

Consistency

  • CleanFlow™ printhead technology prevents ink build-up that can cause downtime in standard inkjet printers
    • Long intervals between routine servicing, with up to 14,000 hours of core module life
    • Dynamic Calibration™ technology automatically adjusts ink jetting parameters to ensure high print quality
    • Automatic printhead cleaning for fast start-up after longer periods of inactivity

Expertise

  • The absence of external air in the internal air pump reduces the potential risk of contaminants entering the ink drop stream
    • The Smart Cartridge™ printing system virtually eliminates ink spills

Functionality

  • Multiple password-protected access levels in the system control menus help prevent accidental input errors
    • Stored print information, with pre-set and calculated fields, minimises the need for user input
    • Simple operation via a bright WYSIWYG display and function keys
    • Stores up to 250 complex messages for easy reuse, with additional capacity available using a standard USB memory device.
