Thermal Transfer Printer
Videojet® 6530 and 6330
New Generation of Videojet DataFlex Thermal Transfer Overprinters
With iAssure™ integrated print quality control technology, a minimal number of wear parts, automatically adjustable electronics, and a quick-change ribbon cassette, the 6530 and 6330 deliver maximum uptime.
The DataFlex® 6330 is a higher-capacity thermal transfer overprinter that enables more productive operation and reduces time spent on quality checks, waste, and rework.
In addition to the features offered by the 6330 model, the 6530 provides print speeds of up to 1,000 mm/s and throughput of up to 700 packs/min, depending on the application and substrate being printed. iAssure™ technology is not supported in ribbon saving mode, high-speed print mode, or high-throughput applications.
| Specification | 6530* | 6330** |
|---|---|---|
| Printer mode | Intermittent and continuous mode | Intermittent and continuous mode |
| Print gap | 0.5 mm | 0.5 mm |
| Ribbon width | 53 mm: 20–55 mm 107 mm: 55–110 mm |
53 mm: 20–55 mm 32 mm: 20–33 mm |
| Barcode printing | EAN 8, EAN 13, UPC-A, UPC-E, Code 39, EAN 128, Code 128, ITF, RSS (incl. 2D composite codes) | EAN 8, EAN 13, UPC-A, UPC-E, Code 39, EAN 128, Code 128, ITF, RSS (incl. 2D composite codes) |
| Max throughput (single-line, continuous) | Up to 700 prints/min | Up to 250 prints/min |
| User interface | TFT SVGA 800 × 480 colour LCD touchscreen, WYSIWYG preview, 3-level password protection | TFT SVGA 800 × 480 colour LCD touchscreen, WYSIWYG preview, 3-level password protection |
| Master/Follower | Control of up to 4 DataFlex® 6530 printers via CLARiTY | Control of up to 4 DataFlex® 6330 printers via CLARiTY |
| Communication | RS232, dual Ethernet, USB, scanner support, ASCII/binary, Windows drivers, ZPL & SATO emulation | RS232, dual Ethernet, USB, scanner support, ASCII/binary, Windows drivers, ZPL & SATO emulation |
| Network browsing | Yes | Yes |
| Continuous mode | ||
| Max print area (W × L) | 53 mm: 53 × 200 mm 107 mm: 107 × 300 mm |
53 mm: 53 × 200 mm 32 mm: 32 × 200 mm |
| Max print speed | 1000 mm/s | 750 mm/s |
| Min print speed | 1 mm/s | 1 mm/s |
| Max prints (single-line) | 53 mm: up to 700/min 107 mm: up to 450/min |
53 mm: up to 250/min 32 mm: up to 250/min |
| Intermittent mode | ||
| Max print area (W × L) | 53 mm: 53 × 75 mm 107 mm: 107 × 75 mm |
53 mm: 53 × 75 mm 32 mm: 32 × 75 mm |
| Max print speed | 53 mm: 800 mm/s 107 mm: 600 mm/s |
53 mm: 750 mm/s 32 mm: 750 mm/s |
| Min print speed | 10 mm/s | 40 mm/s (high-res) / 10 mm/s (reduced-res) |
Code Assurance
iAssure™ technology automatically detects common print errors, reducing unnecessary costs, rework, and additional labour required to correct mistakes.
CLARiTY™ software ensures that the correct code is consistently printed on the correct product.
Productive Uptime
Intelligent Motion™ technology eliminates the need for compressed air and the associated costs and downtime, while increasing print quality consistency and printhead life.
Detect code readability issues that may indicate a potential need for printer maintenance.
Fast and easy ribbon replacement increases productivity.
High ribbon capacity and various ribbon-saving modes extend the time between ribbon changes.
Ease of Use
Designed to withstand the most demanding production conditions.
A minimal number of replaceable parts improves production line operation.
Compact design fits almost any production line.
Simple user access.
Built-In Productivity
Electronically controlled printhead eliminates the need for compressed air.
Automatic print quality maintenance helps avoid the risk of incorrect printer setup by the operator.
The printhead can be replaced quickly and easily, while the minimal number of parts reduces production downtime when replacement is required.
Simple cassette installation.
